Etched Window Graphics - E-Glass®

Enhance Your Windows Etched Window Graphics: A Timeless Appeal Made Simple!

Experience the charm of etched, cut, or sandblasted glass without the hassle. E-Glass Etched Window Graphics are meticulously crafted to create an impression of sophistication and elegance on your windows. These premium graphics are perfect for decorative design applications, elevating the aesthetics of shop windows, glass doors, and various glass-like surfaces.

Key Features:

  1. Can be cut reverse for interior mount or standard for regular mount: Tailor the installation to your specific needs. Whether you prefer an interior mount or a standard mount, E-Glass Etched Window Graphics provide flexibility for a seamless fit.

  2. Designed to give the impression of etched, cut, or sandblasted glass: Achieve a timeless look that exudes class and refinement. These graphics are expertly designed to mimic the elegant appearance of traditional etched, cut, or sandblasted glass.

  3. Sticks to any flat, smooth glass surface: Versatility meets convenience. E-Glass Etched Window Graphics adhere flawlessly to any flat, smooth glass surface, ensuring a secure and long-lasting application.

  4. Comes with application tape applied for easy DIY installation: Enjoy a hassle-free installation process. Our graphics come with pre-applied application tape, making it a breeze to apply them yourself. No need to worry about complicated procedures or additional tools.

Order today. We will immediately get working on your design proof, allowing you to visualize the boundless possibilities and take your brand to a whole new level!

Description:

  • GF 790 Light Etch Cut & Craft vinyl is a 3.0 mil gloss polymeric light glass etch vinyl coated with a permanent solvent acrylic pressure-sensitive adhesive on a 78# clay coated liner. This product is designed to give the frosted effect or an impression of etched, cut or sandblasted glass. GF 790 is designed for roll-fed plotter cut vinyl graphics as well as sheeted material for home craft applications.

    Film Type:
    Etched Polymeric Vinyl
    Film Thickness (mils/μm): 3.0 / 76 (+/- 10%)
    Film Weight: (gsm) 95
    Gloss: (60°) <10
    Opacity: (%) 25
    Tensile Strength (lbs/in): MD > 3000 / CD > 2800
    Elongation (%): MD > 180 / CD > 200
    Dimensional Stability (FTM 14): MD < 0.50 mm / CD < 0.30 mm
    Adhesive Type: Solvent Acrylic
    Adhesive Thickness: (mils/μm) 0.8-1.0 / 20-25
    Adhesive: Color Clear
    Peel Strength on Stainless Steel (lbs/in): (N/25mm) 15 min 2.5 / 11
    Peel Strength on Stainless Steel (lbs/in): (N/25mm) 24 hrs 4.5 / 20
    Peel Strength on Glass (lbs/in): (N/25mm) 24 hrs 4.0 / 18
    Peel Strength on Glass (lbs/in) (N/25mm) 24 hrs 4.5 / 20
    Liner Weight (#/gsm): 78 / 127
    Liner Type: White Clay Coated Kraft
    Liner Thickness (mils/μm): 4.5 / 114
    Release Force @ 360” / min: (g/2”) 75-125
    PERFORMANCE GUIDANCE
    Application Temperature: > +40 °F
    Service Temperature:r -40 °F to 200 °F
    Outdoor Durability: Up to 7 years
Overview

Enhance Your Windows Etched Window Graphics: A Timeless Appeal Made Simple!

Experience the charm of etched, cut, or sandblasted glass without the hassle. E-Glass Etched Window Graphics are meticulously crafted to create an impression of sophistication and elegance on your windows. These premium graphics are perfect for decorative design applications, elevating the aesthetics of shop windows, glass doors, and various glass-like surfaces.

Key Features:

  1. Can be cut reverse for interior mount or standard for regular mount: Tailor the installation to your specific needs. Whether you prefer an interior mount or a standard mount, E-Glass Etched Window Graphics provide flexibility for a seamless fit.

  2. Designed to give the impression of etched, cut, or sandblasted glass: Achieve a timeless look that exudes class and refinement. These graphics are expertly designed to mimic the elegant appearance of traditional etched, cut, or sandblasted glass.

  3. Sticks to any flat, smooth glass surface: Versatility meets convenience. E-Glass Etched Window Graphics adhere flawlessly to any flat, smooth glass surface, ensuring a secure and long-lasting application.

  4. Comes with application tape applied for easy DIY installation: Enjoy a hassle-free installation process. Our graphics come with pre-applied application tape, making it a breeze to apply them yourself. No need to worry about complicated procedures or additional tools.

Order today. We will immediately get working on your design proof, allowing you to visualize the boundless possibilities and take your brand to a whole new level!

Specs

Description:

  • GF 790 Light Etch Cut & Craft vinyl is a 3.0 mil gloss polymeric light glass etch vinyl coated with a permanent solvent acrylic pressure-sensitive adhesive on a 78# clay coated liner. This product is designed to give the frosted effect or an impression of etched, cut or sandblasted glass. GF 790 is designed for roll-fed plotter cut vinyl graphics as well as sheeted material for home craft applications.

    Film Type:
    Etched Polymeric Vinyl
    Film Thickness (mils/μm): 3.0 / 76 (+/- 10%)
    Film Weight: (gsm) 95
    Gloss: (60°) <10
    Opacity: (%) 25
    Tensile Strength (lbs/in): MD > 3000 / CD > 2800
    Elongation (%): MD > 180 / CD > 200
    Dimensional Stability (FTM 14): MD < 0.50 mm / CD < 0.30 mm
    Adhesive Type: Solvent Acrylic
    Adhesive Thickness: (mils/μm) 0.8-1.0 / 20-25
    Adhesive: Color Clear
    Peel Strength on Stainless Steel (lbs/in): (N/25mm) 15 min 2.5 / 11
    Peel Strength on Stainless Steel (lbs/in): (N/25mm) 24 hrs 4.5 / 20
    Peel Strength on Glass (lbs/in): (N/25mm) 24 hrs 4.0 / 18
    Peel Strength on Glass (lbs/in) (N/25mm) 24 hrs 4.5 / 20
    Liner Weight (#/gsm): 78 / 127
    Liner Type: White Clay Coated Kraft
    Liner Thickness (mils/μm): 4.5 / 114
    Release Force @ 360” / min: (g/2”) 75-125
    PERFORMANCE GUIDANCE
    Application Temperature: > +40 °F
    Service Temperature:r -40 °F to 200 °F
    Outdoor Durability: Up to 7 years
